Model: | Hyno GX450H 288.2 | Nominal Voltage: | 288V |
---|---|---|---|
Material: | NIMH Battery | Typical Capacity: | 6500mAh |
Minimum Capacity: | 6000aAh | Cycle Life: | ≥1000cycles |
High Light: | lexus gs450h hybrid battery,hev battery pack |
Battery or charging system warning light is illuminated. Should a battery or charging system warning light illuminate, a mechanic should perform a few basic tests to determine if a battery replacement is needed.
Electrical components don’t work. Once a battery has started to fail, and the voltage produced by the battery drops, then vehicle electrical components can malfunction, such as the security system. If you are experiencing electrical malfunctions, it’s a smart idea to have the battery tested.
Notes: Installing this product should only be attempted by a qualified technician, the voltage of the battery pack is very high, which has the shock hazards, so when installing the battery pack, you should wear insulating gloves and use insulated handle tools.
No. | Description | Unit | Specification | Condition |
1 | Nominal Voltage | V | 288 | |
2 | Operating Voltage | V | 204.0~326.4 | |
3 | Nominal capacity | mAh | 6500 | Standard charge / discharge |
4 | Minimum capacity | mAh | 6000 | Standard charge / discharge |
5 | Nominal Energy | Wh | 1728 | 1 hour rate |
6 | Weight | Kg | 35±0.1 | Standard environment,Accuracy±0.05g Electronic scale |
7 | Power Density | W/kg | >850 | |
8 | Energy Density | Wh/kg | >43 | |
9 | Max. continuous discharge current | C | 20 | 20℃~45℃ |
10 | Max. continuous charge current | C | 15 | |
11 | Storage Temperature | ℃ | -20~35 | |
12 | Operating Temperature | ℃ | -30~55 |
Avoid violent vibration and external force impact, don’t cast, roll, invert, extrude, and stack too high during handling and transportation of battery pack.
Protect the battery pack from rain during the transportation, and the ambient temperature is not over 55℃.
Store the battery pack in a cool and dry place and the temperature range is 5-25℃ when you are not using it.
The SOC of our battery pack is 60%~80% when leaving the factory, in long-term storage, battery should be stored in a charged state (usually the SOC is 80%). Have a charge and discharge maintenance to battery pack when the storage time is over 6 months or battery module’s voltage is 15V,to prevent the battery performance’s decline caused by the self-discharge. The maintenance regulations are as follows:
Hunan Hi-soon Supply Chain Co., Ltd reserves the right to change and revise Product specification without any advance notice.
