Product Details:
Payment & Shipping Terms:
|
Nominal Voltage: | 144V | Material: | NIMH Battery |
---|---|---|---|
Cycle Life: | ≥1000cycles | Package Contents: | Hybrid Battery Pack, Accesories |
Product Condition: | Brand New | Number Of Batteries: | 10 |
High Light: | lexus ct200h hybrid battery,2011 lexus rx450h battery |
Notes: Installing this product should only be attempted by a qualified technician, the voltage of the battery pack is very high, which has the shock hazards, so when installing the battery pack, you should wear insulating gloves and use insulated handle tools.
Item | Specification | |
Dimension | Length (mm) × Width (mm) × Height (mm) | 382 x 34 x 34 |
Approximate Weight (kg) | 21 | |
Typical Capacity(mAh) | 6500 | |
Minimum Capacity (mAh) | 6000 | |
Nominal Voltage (V) | 144 | |
High Temperature Performance ( 55℃ 1C discharge rate) | ≥90% | |
Low Temperature Performance (-20℃ 1C discharge rate) | ≥85% | |
Charge Retention Performance (28days charge retention rate) | ≥80% | |
Working Temperature Range | -20℃ to +55℃ | |
Cycle Life (C/2 charge, 1C discharge) | ≥1000cycles | |
The SOC of our battery pack is 60%~80% when leaving the factory, in long-term storage, battery should be stored in a charged state (usually the SOC is 80%). Have a charge and discharge maintenance to battery pack when the storage time is over 6 months or battery module’s voltage is 15V,to prevent the battery performance’s decline caused by the self-discharge. The maintenance regulations are as follows:
Hunan Hi-soon Supply Chain Co., Ltd reserves the right to change and revise Product specification without any advance notice.
