Product Details:
Payment & Shipping Terms:
|
Nominal Voltage: | 201.6V | Typical Capacity: | 6500mAh |
---|---|---|---|
Minimum Capacity: | 6000aAh | Programming Required: | No |
Dangerous Goods: | No | Vehicle Fit: | 2004-2009 Prius Hybrid |
High Light: | prius hybrid battery pack,prius hybrid battery replacement cells |
There are a lot of other hybrids on the market from many other manufacturers. Many of these help manufacturers meet CAFE standards so they can sell trucks and SUVs and have a smaller hybrid market share. For this article, we are focusing on the evolution of technology in general and the path it has taken to get to the current state. The Toyota Prius was the first and longest-running hybrid, which is why it has been chosen as the bridge to an EV (Electric Vehicle).
Hunan Hi-soon Supply Chain Co., Ltd, is your best supplier of energy storage products with patent technology and guaranteed performance.
Hi-Soon dedicated in the new energy industry and provides the end users with a world-wide energy solution . The Company has been dedicated to hybrid power for 20 years and established a full-industry chain from advanced energy storage materials, advanced battery, automobile battery energy pack, to hybrid automobile assembly system, battery recycling system and hybrid automobile operations to serve the vehicle manufactures and end users. Hybrid car Nimh battery as one of our major product have been served more than 100,000 hybrid passenger vehicles across the continents
In addition to sustainable social change, we believe passionately in customer service, giving our employees proper training and knowledge, and making the highest quality products. We are 100% positive we are making the world a better place.
Item | Specification | |
Dimension | Length (mm) × Width (mm) × Height (mm) | 550 x 294 x 110 |
Approximate Weight (kg) | 30 | |
Typical Capacity(mAh) | 6500 | |
Minimum Capacity (mAh) | 6000 | |
Nominal Voltage (V) | 201.6 | |
High Temperature Performance ( 55℃ 1C discharge rate) | ≥90% | |
Low Temperature Performance (-20℃ 1C discharge rate) | ≥85% | |
Charge Retention Performance (28days charge retention rate) | ≥80% | |
Working Temperature Range | -20℃ to +55℃ | |
Cycle Life (C/2 charge, 1C discharge) | ≥1000cycles | |
The SOC of our battery pack is 60%~80% when leaving the factory, in long-term storage, battery should be stored in a charged state (usually the SOC is 80%). Have a charge and discharge maintenance to battery pack when the storage time is over 6 months or battery module’s voltage is 15V,to prevent the battery performance’s decline caused by the self-discharge. The maintenance regulations are as follows:
Notes: Installing this product should only be attempted by a qualified technician, the voltage of the battery pack is very high, which has the shock hazards, so when installing the battery pack, you should wear insulating gloves and use insulated handle tools.
Hunan Hi-soon Supply Chain Co., Ltd reserves the right to change and revise Product specification without any advance notice.
