Payment & Shipping Terms:
|Nominal Voltage:||201.6V||Material:||NiMH Battery|
|Cycle Life:||≥1000cycles||Voltage Of Battery Module:||14.4V|
|MOQ:||One Pack||Payment Terms:||Option As Per Commercial Terms|
toyota prius battery cell replacement,
prius hybrid battery replacement cells
If the battery has not been replaced and data stream shows wandering voltage, then it’s time to dig into the battery case. On a Prius, there are several visual clues that can lead to the replacement of the battery. Disable the high voltage circuit, then take the top of the battery case off and look at all the battery blocks—if you see any that are weeping a clear or blue liquid, this is electrolyte from the battery cells. The electrolyte in a Prius battery is COH (Potassium Hydroxide) and when it leaks out, it’s as conductive as a pool of liquid copper, so be careful when you see it.
|Dimension||Length (mm) × Width (mm) × Height (mm)||550 x 294 x 110|
|Approximate Weight (kg)||30|
|Minimum Capacity (mAh)||6000|
|Nominal Voltage (V)||201.6|
|High Temperature Performance ( 55℃ 1C discharge rate)||≥90%|
|Low Temperature Performance (-20℃ 1C discharge rate)||≥85%|
|Charge Retention Performance (28days charge retention rate)||≥80%|
|Working Temperature Range||-20℃ to +55℃|
|Cycle Life (C/2 charge, 1C discharge)||≥1000cycles|
The SOC of our battery pack is 60%~80% when leaving the factory, in long-term storage, battery should be stored in a charged state (usually the SOC is 80%). Have a charge and discharge maintenance to battery pack when the storage time is over 6 months or battery module’s voltage is 15V,to prevent the battery performance’s decline caused by the self-discharge. The maintenance regulations are as follows:
Notes: Installing this product should only be attempted by a qualified technician, the voltage of the battery pack is very high, which has the shock hazards, so when installing the battery pack, you should wear insulating gloves and use insulated handle tools.
Hunan Hi-soon Supply Chain Co., Ltd reserves the right to change and revise Product specification without any advance notice.
Contact Person: Sales Manager
